What our parts do, when to use them, how to pick them.
A category-by-category reference for every product family in the Magnias catalog, protection, power management, discrete, and signal. Read it linearly, search a specific part type, or jump to a category from the index below.
No FAQs match that search. Try a different keyword, or use the part-number search in the header to find a specific device.
ESD diodes, ePoly polymer ESD suppressors, TVS, thyristor surge suppressors, common-mode filters and chip fuses: keep transients and faults away from your IC pins and power rails.
ESD Protection Diodes
Tiny diodes that protect your IC pins from human-body static and other transient events.
TVS Diodes (General)
Workhorse transient voltage suppressors for power rails and lower-speed signal lines.
Load Dump TVS (DO-218)
Heavy-duty TVS purpose-built for automotive 12 V / 24 V load-dump surge events.
Short-to-VBUS Protection
Protection ICs that keep USB Type-C CC and SBU pins safe when they are shorted to VBUS.
Common-Mode Filter + ESD (CMF+ESD)
Two-in-one parts: EMI filter for differential pairs plus integrated ESD protection.
TSS (Thyristor Surge Suppressor)
Crowbar-style surge protectors for telecom and high-energy line protection.
ePoly (Polymer ESD Suppressor)
ESD protection with about 0.05 pF of capacitance, for antenna, RF and very high-speed lines.
Chip Fuses
One-shot over-current protection for fault containment.
LDOs, buck and boost converters, PMICs, load switches, and voltage references: generate and gate every rail on the board.
LDO (Low-Dropout Linear Regulator)
Quiet, simple, low-noise voltage regulators for clean rails.
Buck Converter (Step-Down DC-DC)
High-efficiency step-down switching converters for the heart of any modern power tree.
Boost Converter (Step-Up DC-DC)
Step-up switching converters when you need more voltage than your input rail provides.
PMIC (Power Management IC)
Multiple rails, sequencing, supervision, and protection in one integrated chip.
Power Switch / Load Switch (PSW)
Integrated MOSFET switches with controlled turn-on, soft-start, and protection.
Voltage Reference
Stable, low-noise voltage source for ADCs, DACs, and precision analog circuits.
MOSFETs, BJTs, Zeners, Schottkys, switching diodes, rectifiers, and bridges: the workhorse silicon behind every analog and power design.
Zener Diodes
Precision voltage references and clamping diodes for regulation and protection.
Switching Diodes
General-purpose fast-recovery signal diodes for steering, clamping, and small-signal rectification.
Schottky Diodes (SKY)
Low-forward-drop, fast diodes for power rectification and low-loss steering.
Fast Recovery Rectifiers
Silicon rectifiers with short reverse-recovery time for high-frequency power converters.
Bridge Rectifiers
Four-diode AC-to-DC conversion in one package.
MOSFETs
The workhorse switch and amplifier of modern electronics.
BJT (Bipolar Junction Transistors)
Classic current-controlled transistors, still the right choice for analog and low-cost switching.
Analog switches, multiplexers, logic gates, comparators, level shifters, USB-to-serial and USB-to-Ethernet bridges, HDMI/DisplayPort control-link boosters, and residual current sensors: route, condition, translate and monitor signals.
SPDT Analog Switch
Single-pole double-throw analog switching for signal routing.
Multiplexer (MUX)
Many-to-one signal routing for sensor scanning and channel selection.
Logic Gates
Single-gate and small-scale CMOS logic for glue, level shifting, and signal conditioning.
Voltage Comparator
Convert analog voltage to digital logic level.
Level Shifter
Bidirectional voltage-domain translation for mixed-voltage systems.
HDMI / DisplayPort Signal Booster (Control Links)
ESD protection, level shifting and drive for the AUX / DDC and HPD lines of a DisplayPort or HDMI source.
HDMI to VGA Converter
Digital-to-analog video converter for legacy VGA monitors and projectors.
USB Bus Converter Chip (USB to Serial)
Add a UART, RS-232, RS-485 or RS-422 port to any host with a USB port.
Ethernet Controller (USB to Ethernet)
Add a wired 10/100 Mbps Ethernet port to any device with a USB port.
Current Sensor (Residual Current Monitor)
Detect AC and DC leakage current in EV chargers and other mains equipment.
Need help picking a specific part?
Your Magnias FAE can recommend the right device for your topology, package constraints, and qualification requirements.
